Cangzhou Ouguan Packing Machinery Co.,Ltd has been investing a lot in product development and has gained positive results. Having carried out multiple tests, our technical staff has proved the use of technology ensures Corrugated Box Automatic Carton Printing Machine Printer Slotter Machine performance can be fully played out.Customers engaged in the field(s) of Paper Product Making Machinery speak highly of our product. It is the support of our customers that propels us to continue to move forward. Cangzhou Ouguan Packing Machinery Co.,Ltd will keep providing high-quality products and professional services as always for customers. In addition, talents are the core pillar of a company. We will organize regular training on our staff to improve their skills.
| Applicable Industries: | Hotels, Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Food & Beverage Shops, Other, Advertising Company | Showroom Location: | None |
| Condition: | New | Product Type: | cardboard machine |
| Processing Type: | Printing Machine | Place of Origin: | Hebei, China |
| Brand Name: | Ouguan | Voltage: | 380V/220V |
| Dimension(L*W*H): | Depend on model | Weight: | 10000 kg |
| Warranty: | 1 Year | Production Capacity: | 100-150 pcs/min |
| Machinery Test Report: | Provided | Video outgoing-inspection: | Provided |
| Marketing Type: | New Product 2021 | Warranty of core components: | 1 Year |
| Core Components: | PLC, Pressure vessel, Other, Engine, Gear, Motor, Pump, Bearing, Gearbox | Name: | Corrugated Automatic Carton Printing Machine Printer Slotter Machine |
| Color: | Customer's Requirements | Suitable for: | Cardboard |
| Control: | PLC+Touch Screen | Key Selling Points: | Auto |
| Speed: | 150 pcs/min | Function: | Cardboard Slotting |
| Type: | Automatic | Keyword: | Printing Machine |
| Certification: | CE, CE ISO | After Warranty Service: | Video technical support, Online support, Spare parts, Field maintenance and repair service |
| Local Service Location: | None | After-sales Service Provided: | Video technical support |
The whole machine is adopted international famous brand appliances "Schneider" .The quality is stable and reliable.
The machine shaft, roller are adopted high quality steel, grinding processing, high precision computer dynamic balancing correction and surface hard chromium plating.
The engine drive gear is adopted 40Cr, the shaving machining nitrogen treatment, tinted with high precision.
Machine transmission parts (shaft, gear joint) is adopted free key connection (LOCK -ALX),clears the connection gap.lt is suitable for long-term high speed running with high torque.
The machine drive bearing ,important driving parts adopt three big domestic famous brand:Hava los,simple maintenance,long service life.
The engine lubrication system is adopted automatic spray type lubrication, equipped with auto oil level balance system.
It adopts Working gap adjustment, self-locking type worm wheel and worm gear device , quick performance and convenient adjustment.
The main motor is adopted frequency conversion control.Ilt makes start, running more steadily and saves more energy.
Rotary die-cutting department and rotary slotting department is optional for you.
Option : ceramic anilox roller stacking.
| Color group | to be configured according to user's needs | ||
| Width of machine inside | 2600mm | 2800mm | 3000mm |
| Max. paper size | 1200×2400mm | 1400×2600mm | 1600×2800mm |
| Max. printing size | 1200×2300mm | 1400×2500mm | 1600×2700mm |
| Skip feeding paper | 1400×2400mm | 1600×2600mm | 1800×2800mm |
| Printing plate thickness | 7.2mm | 7.2mm | 7.2mm |
| Max. die cutting size | 1200×2300mm | 1400×2500mm | 1600×2700mm |
Related Products
| Product Name | Corrugated Box Automatic Carton Printing Machine Printer Slotter Machine flexo printer slotter die-cutter machine |
|---|---|
| SKU | OG-797066 |
| Place of Origin | Hebei, China |
| Brand Name | OUGUAN |
| Stock Status | In Stock |
Cangzhou Ouguan Packaging Machinery Co., Ltd. is a professional manufacturer of corrugated carton box making machines with over 20 years of experience. We provide one-stop solutions including 2/3/5/7 ply corrugated paperboard production lines, flexo printer slotter die-cutters, folder gluers, and more.
