After years of development, Cangzhou Ouguan Packing Machinery Co.,Ltd has gained strong capabilities in production and R&D, which allows us to develop new products to keep close up with industry development. Our range of Paper Product Making Machinery are made with the best ingredient. Since our inception, Cangzhou Ouguan Packing Machinery Co.,Ltd have been striving forward with the aim of being a leading company in the globe. We will focus more on improving our R&D capabilities and upgrading technologies in order to develop more creative products, therefore leading the industry trends and keeping us competitive in the market.
| Applicable Industries: | Hotels, Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Food & Beverage Shops, Other, Advertising Company | Showroom Location: | None |
| Condition: | New | Product Type: | cardboard machine |
| Processing Type: | Printing Machine | Place of Origin: | Hebei, China |
| Brand Name: | Ouguan | Voltage: | 380V/220V |
| Dimension(L*W*H): | Depend on model | Weight: | 65000 kg |
| Warranty: | 1 Year | Production Capacity: | 100-150 pcs/min |
| Machinery Test Report: | Provided | Video outgoing-inspection: | Provided |
| Marketing Type: | New Product 2020 | Warranty of core components: | 1 Year |
| Core Components: | PLC, Pressure vessel, Other, Engine, Gear, Motor, Pump, Bearing, Gearbox | Name: | Printing Die Cutting slotting Machine |
| Color: | Customer's Requirements | Suitable for: | Cardboard |
| Control: | PLC+Touch Screen | Key Selling Points: | Auto |
| Speed: | 150 pcs/min | Function: | Printing Carton |
| Type: | Automatic | Keyword: | Ink Printing Die-Cutting Machine |
| Certification: | CE |
The whole machine is adopted international famous brand appliances "Schneider" .The quality is stable and reliable.
The machine shaft, roller are adopted high quality steel, grinding processing, high precision computer dynamic balancing correction and surface hard chromium plating.
The engine drive gear is adopted 40Cr, the shaving machining nitrogen treatment, tinted with high precision.
Machine transmission parts (shaft, gear joint) is adopted free key connection (LOCK -ALX),clears the connection gap.lt is suitable for long-term high speed running with high torque.
The machine drive bearing ,important driving parts adopt three big domestic famous brand:Hava los,simple maintenance,long service life.
The engine lubrication system is adopted automatic spray type lubrication, equipped with auto oil level balance system.
It adopts Working gap adjustment, self-locking type worm wheel and worm gear device , quick performance and convenient adjustment.
The main motor is adopted frequency conversion control.Ilt makes start, running more steadily and saves more energy.
Rotary die-cutting department and rotary slotting department is optional for you.
Option : ceramic anilox roller stacking.
| Color group | to be configured according to user's needs | ||
| Width of machine inside | 2600mm | 2800mm | 3000mm |
| Max. paper size | 1200×2400mm | 1400×2600mm | 1600×2800mm |
| Max. printing size | 1200×2300mm | 1400×2500mm | 1600×2700mm |
| Skip feeding paper | 1400×2400mm | 1600×2600mm | 1800×2800mm |
| Printing plate thickness | 7.2mm | 7.2mm | 7.2mm |
| Max. die cutting size | 1200×2300mm | 1400×2500mm | 1600×2700mm |
Related Products
| Product Name | pizza box printing slotting die cutting machine for carton packaging machine edge feed automatic carton flexo printing m flexo printer slotter die-cutter machine |
|---|---|
| SKU | OG-796151 |
| Place of Origin | Hebei, China |
| Brand Name | OUGUAN |
| Stock Status | In Stock |
Cangzhou Ouguan Packaging Machinery Co., Ltd. is a professional manufacturer of corrugated carton box making machines with over 20 years of experience. We provide one-stop solutions including 2/3/5/7 ply corrugated paperboard production lines, flexo printer slotter die-cutters, folder gluers, and more.
