High level Full automatic Flat die cutting machine Flatbed die-cutting and creasing machine

High level Full automatic Flat die cutting machine is made of raw materials that are offered by reliable suppliers and have been through meticulous tests. After several discussions of our design team, Corrugated paperboard production line,Flexo printer slotter die-cutter machine,Single facer machine,corrugated carton machine has finally gained a totally eye-catching appearance and unique style. It has many advantages, making it highly valuable.

In Stock

Send Inquiry

SKU: OG-795850

Always putting an emphasis on the improvement of the research and development, Cangzhou Ouguan Packing Machinery Co.,Ltd has finally developed High level Full automatic Flat die cutting machine. The product with improved properties and features is expected to lead the trend of the industry. Technological innovation is an important factor for products to form core competitiveness and maintain competitive advantage. For the growth and development of our company, Cangzhou Ouguan Packing Machinery Co.,Ltd will never stop upgrading and developing technologies to enhance our core competitiveness. Our vision is to become a famous enterprise in the global market.

Warranty:	2 years	Type:	Other
Applicable Industries:	Other	Showroom Location:	None
Video outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	Ordinary Product	Warranty of core components:	1 Year
Core Components:	PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump	Condition:	New
Application:	Machinery & Hardware	Packaging Type:	Film
Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Mechanical	Voltage:	220v/380v/415v
Power:	15.5KW	Place of Origin:	Hebei, China
Brand Name:	OUGUAN	Weight:	7 KG
Dimension(LWH):	201025001950mm	Key Selling Points:	Easy to Operate
speed:	80pcs/min	machine type:	cutting & creasing machine
After Warranty Service:	Video technical support, Online support, Spare parts, Field maintenance and repair service	Local Service Location:	None
After-sales Service Provided:	Field maintenance and repair service	Certification:	CE

PLease Contact me to get the video , quotation and more information

Full automatic die cutting and creasing machine

I. Machine Introduction:

The MY-1060 Automatic Die Cutting and Creasing Machine is the main equipment for making high-grade color box, plug and different shapes of ink cartons.

The machine adopts Anchuan servo system, Gogol four axes motion controller, non-pressure feeding system, high strength gripper teeth row, whole swing front guide, automatic pushing guide, high precision interval structure, pneumatic locking plate. Pneumatic clutch, overload protector, automatic paper collecting, makes our machine has a short paper feeding distance, positioning correctly, paper collecting in order, can also do non-gripper die cutting.

II. Technical Parameters:

Item		Parameters	Parameters	Parameters	Parameters
Model		MY-1060	MY-1080	MY-1100	MY-1200
Die cutting type		Pressed flat die cutting(Lower side is movable while upper side is unmovable)	Pressed flat die cutting(Lower side is movable while upper side is unmovable)	Pressed flat die cutting(Lower side is movable while upper side is unmovable)	Pressed flat die cutting(Lower side is movable while upper side is unmovable)
Max paper transmitting size		1060*750mm	1080*780mm	1100*780mm	1200*780mm
Min paper transmitting size		400*370mm	400*370mm	400*370mm	400*380mm
Max die cutting size		1050*730mm	1050*760mm	1050*770mm	1050*770mm
Min gripper size		5mm	5mm	5mm	5mm
Max die cutting pressure		300N/cm²	300N/cm²	300N/cm²	300N/cm²
Paper processed	Ivory board	0.1-0.3mm	0.1-0.3mm	0.1-2mm	0.1-1.5mm
Paper processed	Corrugated board	Less than 4mm	Less than 4mm	Less than 5mm	Less than 5mm
Die cutting precision		±0.1mm	±0.1mm	±0.1mm	±0.1mm
Max die cutting speed		6500 sheets/h	6500 sheets/h	6500 sheets/h	6500 sheets/h
Max feeding pile height		1000mm(above the level)	1100mm(above the level)	1100mm(above the level)	1100mm(above the level)
Min feeding pile height		1000mm(above the level)	1100mm(above the level)	1100mm(above the level)	1100mm(above the level)
Total power		13.5kw	15kw	17kw	17kw
Total weight		15T	16T	17T	18T
Overall size		765021002100mm (Not including the pedal)	765021002100mm (Not including the pedal)	765021002100mm (Not including the pedal)	765021002100mm (Not including the pedal)

High level Full automatic Flat die cutting machine

Product Name	High level Full automatic Flat die cutting machine Flatbed die-cutting and creasing machine
SKU	OG-795850
Place of Origin	Hebei, China
Brand Name	OUGUAN
Stock Status	In Stock

Send Inquiry for this product

Inquiry

High level Full automatic Flat die cutting machine Flatbed die-cutting and creasing machine

PLease Contact me to get the video , quotation and more information
